Specifications:
Clamping diameter: 48 mm
Current: 1,000 A AC / 1,500 A DC
Voltage up to 1,200 VAC / 1,700 VDC
Resistance and audible continuity
Temperature
Automatic AC/DC detection
TrueInrush current measurement
Hold, Min, MAX
RELative (ΔX) and differential (ΔX/X) measurements
Adapter function
Adapter function
CAT IV 1,000 V / CAT III 1,500 V
IP54 protection rating
Ini demo, bisa diisi apa saja
Ini demo, bisa diisi apa saja
Ini demo, bisa diisi apa saja
Ini demo, bisa diisi apa saja
Produk Tridinamika tersertifikasi jaminan SNI
Ini hanya demo
Free
Jasa Pengiriman kilat oleh tim Tridinamika
Ini hanya demo saja
2-3 Days
Free
To deal with the highest level of low-voltage electrical installations, the F400 Series has a high protection rating and is ideal for maintenance, testing, monitoring and diagnostics on medium-power installations.
Equipped with a fast 12-bit TRMS digital acquisition system, F404 clamps offer particularly accurate measurements whatever the signal’s waveform.
| Brand |
Chauvin Arnoux |
|---|
