**AC Current Source**
**Amplitude Power**
6×35A @ 424VA max each
3×70A @ 670VA max each
**Accuracy**
Typical <0 015%Rd + 0 005%Rg
Guaranteed <0 04%Rd + 0 01%Rg
**Range**
Range I 3A
Range II 35A Automatic Range
**DC Offset** <3mA Typical <10mA Guaranteed
**Resolution** 1mA
**Distortion**
Typical <0 025%
Guaranteed <0 07%
**Response Time** <100µs
**DC Current Source**
**Amplitude Power** 3×20A @ 400W max
**Accuracy**
±5mA @ <1A
±0 2% @ ≥1A
**Response Time** <100µs
**AC Voltage Source**
**Amplitude Power** 6×310V @ 105VA max each
**Accuracy**
Typical <0 015%Rd + 0 005%Rg
Guaranteed <0 04%Rd + 0 01%Rg
**Range**
Range I 30V
Range II 310V Automatic Range
**DC Offset** <10mV Typical <60mV Guaranteed
**Resolution** 1mV
**Distortion**
Typical <0 015%
Guaranteed <0 05%
**Response Time** <100µs
**DC Voltage Source**
**Amplitude Power**
6×350V @ 100W max
3×700V @ 150W max
**Accuracy**
±10mV @ <5V
±0 2% @ ≥5V
**Response Time** <100µs
**Frequency Phase Angle**
**Frequency Range** DC ~ 1000Hz 3000Hz transient
**Frequency Accuracy** ±0 5ppm
**Resolution** 0 001Hz
**Phase Range** 360°~360°
**Phase Accuracy**
Typical <0 02° @ 5060Hz
Guaranteed <0 1°
**Phase Resolution** 0 001°
**Auxiliary DC Supply Battery Simulator **
**Voltage Range**
8 ~ 60Vdc Max 1 16A Accuracy <2%
60 ~ 120Vdc Max 0 58A Accuracy <1%
120 ~ 350Vdc Max 0 2A Accuracy <0 5%
**Power** >69W max
**Resolution** 10mV
**Protection** Short circuit Overload Protection
**Isolation** Fully isolated
**Binary Input**
**Isolation** 10 pairs electrically isolated
**Input Impedance** 5kΩ – 13kΩ Dry contact
**Input Voltage Range** 0V – 300Vdc
**Sampling Rate** 10kHz
**Time Resolution** 10µs
**Time Accuracy** ±1ms <1s ±0 1% ≥1s
**Debounce Time** 0 25ms Software controlled
**Binary Output**
**Quantity** 4 pairs
**Type** Fast speed transistor Programmable
**AC Capacity** Max 250V AC 0 5A
**DC Capacity** Max 250V DC 0 5A
**Isolation** All pairs isolated
**Time Synchronization**
**Satellite Sync** GPS Beidou supported
**Fiber IRIG B** 2 × ST Tx Rx
**Electric IRIG B** 1 × Phoenix Terminal Tx Rx
**External Trigger** 1 × Phoenix Terminal
**Sync Error** <10µs
**Communication Interface**
**Ethernet** 2 × RJ45 10100M
**Wi Fi** Built in Wi Fi DHCP service
**Serial Port** 1 × RS232
**USB** 2 × USB2
**Weight Size**
**Size** 390mm × 256mm × 140mm
**Weight** 10kg
**Display** 9 7” LCD Touch Screen
**Keypad** Numeric Directional Keys
**Power Supply**
**Voltage** 220V110V AC
**Allowable Voltage** 85 265VAC 127V – 350VDC
**Frequency** 50Hz 47 63Hz allowable
**Current** 10A @ 220V 16A @ 110V
**Power Consumption** Max 1200VA
**Connection Type** Standard AC socket 60320
**Working Environment**
**Operating Temperature** 10°C ~ +55°C
**Humidity** 5% – 95% Non condensation
**Storage Temperature** 20°C ~ +70°C
**Altitude** ≤2000m 80kPa – 110kPa
Ini demo, bisa diisi apa saja
Ini demo, bisa diisi apa saja
Ini demo, bisa diisi apa saja
Ini demo, bisa diisi apa saja
Produk Tridinamika tersertifikasi jaminan SNI
Ini hanya demo
Free
Jasa Pengiriman kilat oleh tim Tridinamika
Ini hanya demo saja
2-3 Days
Free
Basic Functions
The Kingsine KF86P universal relay test kit marks a multipurpose light weight field portable secondary injection test kit It is capable of testing a wide variety of electro mechanical solid state and microprocessor based protective relays motor overload relays IEC61850 testing and similar protective devices
12 Analog Channels outputs 6x35A 6x310V Each output channels are independent and simultaneous control of magnitude Phase angle and frequency values able to inject DC AC sine wave and up to 60x harmonics
Lightweight <10kg easy carry on flight journey The unit can be operated either manually via built in 13 3 touchscreen and keypad or placed under full computer control via the KRT software running on a PC Variable battery simulator 24~350Vdc 70Watts max output Easily supply power for most protection devices Fully function KRT software for test management graphical test modules template organized XrioRio importexport testing result review auto result assessment and report generate etc Transient play back up to 3KHz 8x1001000Mbit Fiber port for IEC61850 SMV and GOOSE simulations Inbuilt GPS and IRIG B synchronized end to end testing capability 10 binary input dry contacts or 0 300V potential contacts capability; 4 fast binary outputs isolated each and with <1ms response time Anti clipping detect Wrong wiring connect alarm and self protect overload and overheat protection AC 85~265 DC 127 350 power supply World wide range power supply compatibility 3 Year free warranty and life long maintenance Free software upgrade Learn more about the testing software designed for user friendliness multifunctional and cost effectiveness Advance Feature Complied IEC61850 edition 1 0 2 0 standard Transducer calibration Energy meter calibration Mechanical Electronic meters 10 Low level analog outputs 8 Voltages + 2 Currents up to 8V20mA max Key Points Innovative Plug and Play After sales Service Advantages： Simple structure beginners can achieve independent installation Reduced after sales costs Shortened after sales time Goal Complete after sales within 20 working days As a highly flexible solution for protection relay testing the KF86P universal relay test kit utilizes innovative technology module design and a simple internal structure ensuring a higher level of product quality and providing assurance for a three year warranty commitment Besides this secondary injection kit also contributes to achieving the quality objective of a 15 year product service life For after sales maintenance only module replacement is required and there is no need for accuracy calibration after module replacement Once assembly is complete it can be used directly truly achieving Plug and Play Public disclosure the internal structure is visualized as shown in the following diagram Internal Structure of KF86P Universal Relay Test Set Other KINGSINE Numerical Relay Testing Devices You May Also Like Universal relay test kit KF85P Protection relay test set K3163I Multi amp relay test set K3166I Transformer relay testing K3130I Relay tester KF900A IEC61850 relay testing KF932
| Brand |
Kingsine |
|---|
